32PCS 105AH LiFePO4 cells
51.2Vdc 10.75KWH rated capacity
Long cycle life 6000 times
IP65 Protection
Unique automatic calibration active banlancing technology BMS syestem
Standard CAN &RS485 communication port, can meet
the require ment of several packages to connect in
parallel, Master & Slave relationship, Monitor and
other functions.Compatible with other brand
inverters' communication protocols.
Technical Parameters
| Normal specification | |||
| Model | LFPM48210H | ||
| Rated Voltage | 51.2V | ||
| Rated Capacity | 210Ah | ||
| Rated Energy | 10.75KWH | ||
| Cell Configuration | 16S2P | ||
| Normal specification | |||
| Model | LFPM48210H | ||
| Rated Voltage | 51.2V | ||
| Rated Capacity | 210Ah | ||
| Rated Energy | 10.75KWH | ||
| Cell Configuration | 16S2P | ||
| Normal specification | |||
| Model | LFPM48210H | ||
| Rated Voltage | 51.2V | ||
| Rated Capacity | 210Ah | ||
| Rated Energy | 10.75KWH | ||
| Cell Configuration | 16S2P | ||
| Battery Cell | 3.2V105AH 32PCS(EVE LF105) | ||
| Life cycles(80%DOD,25℃) | 6000 Cycles | ||
| Standard Charge | |||
| Operation temperature range ©charging | 0~60℃ | ||
| Rated charge voltage | 56V | ||
| Max charge voltage | 56.8±0.4V | ||
| Overcharge protection | 58.4±0.4V | ||
| Allowed MAX charge current | 205A | ||
| Peak charge current | 210A | ||
| Rated charge current | 200A | ||
| Recommend charge current | <200A | ||
| Standard discharge | |||
| Operation temperature range ©discharging | '-35~60°C | ||
| Output Voltage Range | 43.2~56.8Vdc | ||
| Recommend Working Range | 46.4~56Vdc | ||
| Storage and Transportation requirements | |||
| Storage Temperature | Less than 1 month | '-20~35°C | |
| Storage Temperature | Less than 6 month | '-10-30°C | |
| Storage Humidity | 45~75%RH | ||
| SOC | Storage | 60~75% SOC | |
| SOC | Transport | 45~55% SOC | |
Our energy storage systems can be tailored to meet the exact requirements of your project and the applications it will be used for. Whatever your needs, we can give you a reliable, bankable battery asset. Calculation is an estimate based on typical use of electrical appliances Customer experience will vary based on location and actual usage. Some appliances may not be compatible with storage system. Pls consult specilist or YIY team before installation to determine which appliances and devices are compatible.
*Maximum single PV charging power:50KW
